Exmark Lazer Z E-Series with 23.5HP* Kawasaki FX730V Engine and 48" UltraCut Series 4 (2-Blade) Deck (LRE730GKA48DA3)
Vendor : Exmark
Product Type : Zero Turn Mower
Sku : Exmark Lazer Z E-Series with 23.5HP* Kawasaki FX730V Engine and 48" UltraCut Series 4 (2-Blade) Deck (LRE730GKA48DA3)-LRE730GKA48DA3
Couldn't load pickup availability
Description:
As the most affordable model in the Lazer Z line, the all-new 2025 Lazer Z E-Series delivers an unbeatable combination of cut quality, productivity, durability and value. Select from 48-, 52-, or 60-inch UltraCut Series 4 cutting decks, all equipped with a newly redesigned discharge chute that distributes clippings over a wider area. A choice of twin-cylinder Kawasaki, Kohler, or Vanguard twin-cylinder commercial engines are available, all equipped with heavy-duty external air filters. Power is delivered through unitized Hydro Gear pump and motor units for up to 11 mph forward ground speeds. A new full-suspension operator seat increases operator comfort during long work days.
Specifications:
- UPC: 193308242187
- Width / Cutting Deck: 48"
- Drive: Hydro-Drive
- Starter: Electric
- Steering Control: Hydraulically dampened twin levers (adjustable fore/aft and height)
- Caster Forks: 0.50" thick caster yoke arms
- Front Caster Tires: 13 x 6.5-6, smooth tread, pneumatic, sealed ball bearings
- Drive Tires: 24 x 9.5-12, 4-ply Super Turf TL
- Safety Package: Operator Presence Controls (OPC), drive system interlock, safety interlock indicators
- Parking Brake: Lever-actuated internal wet disc brake
- Tractor Frame: Unibody, welded, heavy-duty 1.5" x 3" tubular steel
- Blade Spindles: No maintenance, sealed, non-greasable; 7.75" cutter housing, 25mm spindle shaft
- Electrical: 12V battery, 15-amp alternator
- Standard Features: Engine hour meter, cup holder
- Seat: Deluxe suspension seat, foam flip-up armrests, fore/aft adjustment, integral safety switch
- Engine Brand: Kawasaki®
- Engine Model: FX730V
- Engine Displacement: 726cc
- Engine Series: V-Twin
- Fuel System: Carbureted
- Speed: Infinitely variable (0–11.0 mph forward, 0–6.0 mph reverse)
- Engine Speed: 3700 RPM
- Air Filter: Heavy-duty canister air filtration system
- Fuel Capacity: 9.5-gallon single fuel tank
- Drive Description: Dual Hydro-Gear ZT-4400 hydrostatic transmission
- Fuel Type: Gas (Carbureted)
- PTO Engagement: MagStop Electromagnetic 175 ft-lb clutch with spot brake
- Drive Wheel Release: Allows movement without engine running
- Fuel Indicator: Mechanical float
- Deck Lift: Foot-controlled, adjusts cutting height (1.5" to 5.5" in 0.25" increments)
- Carb Compliant: No
- ROPS: 2-post foldable ROPS with seat belt and latch
- Deck Style: Floating Deck (UltraCut Series 4)
- Deck Construction: 10-gauge alloy top, 7-gauge side skirt, reinforced spindle mounts
- Blade Tip Speed: ~18,500 fpm
- Blades: 2 blades, 24.50" length
- Dimensions:
- Width: 61.2"
- Height: 70.1"
- Length: 87.8"
- Curb Weight: 1017 lbs
Width | Weight | Height | Length |
---|---|---|---|
61.2 Inch | 1017 Pounds | 70.1 Inch | 87.8 Inch |
