Description:

For more than 30 years, the Exmark Lazer Z has been the choice of more landscape professionals than any other zero-turn mower. For pros that demand the absolute best durability, productivity, cut quality and innovation, the Lazer Z X-Series is the number one choice. With more configuration options than any other Exmark mower, the Lazer Z X-Series is the pinnacle of state-of-the-art commercial mowers. Choose from 52-, 60-, or 72-inch UltraCut Series 6, or massive 96-inch UltraCut Rear Discharge cutting decks. Our exclusive flow control baffles and Adapt tools-free deck rake adjustment deliver Exmark Signature cut quality and higher cutting speeds in any mowing conditions. Powered by a choice of state-of-the-art big block EFI V-Twin commercial engines from Kawasaki, Kohler and Vanguard, the Lazer Z X-Series powers through the largest jobs with ease. A long-travel full suspension operator seat features isolation bumpers to deliver a smoother ride for reduced operator fatigue.

When you’re looking for the pinnacle of power, performance, cut quality and durability in a commercial zero-turn mower, the Lazer Z X-Series is the obvious choice.

Specifications:

• UPC: 193308241487
• Width (cutting deck): 52"
• Length: 86.1"
• Width (overall): 64.8"
• Height (ROPS up): 70.5"
• Curb Weight: 1,200 lbs
• Fuel Capacity: 12-gallon single tank with single fill
• Fuel Type: Gas, carbureted
• Carb Compliant: No

Chassis & Frame

• Frame: Welded 1.5" x 3" heavy-duty tubular steel (unibody design)
• Caster Forks: 0.50" thick yoke arms
• Front Tires: 13 x 6.5-6, smooth tread, semi-pneumatic
• Rear Tires: 23 x 9.5-12, 4-ply Grassmaster TL

Operator Station

• Seat: Deluxe, 3-tone suspension seat with Elastomeric Vibration Control
• Seat Mounting: Full 3-plane isolation, slide, and flip-up
• Controls: Hydraulically dampened twin levers with 2-position height and 3-position dampers
• Standard Features: Engine hour meter, USB, LED lights, phone tray, cup holder

Drive System

• Type: Two Exmark-exclusive Parker unitized pump & wheel motor systems
• Transmission: Hydro-drive, infinitely variable
• Speed (FWD): 0–10.0 mph
• Speed (REV): 0–6.0 mph
• Drive Release: Yes (move unit without engine)
• Transmission Cooling: Integrated cooling fans, 1.7 qt reservoirs, spin-on filters

Electrical & Safety

• Battery: 12V
• Alternator: 15-amp
• PTO Clutch: MagStop electromagnetic, 200 ft-lb with spot brake
• Safety Systems: OPC, interlocks, indicators
• ROPS: 2-post foldable with seatbelt and latch

Deck System

• Style: Full-floating UltraCut Series 6
• Construction:
• 10-gauge formed top (fully seam welded)
• 7-gauge side skirts
• 7-gauge welded spindle mounts
• Blades: 3 blades @ 20.5"
• Blade Tip Speed: ~18,500 fpm
• Cutting Heights: 1.0"–5.5" (¼" increments)
• Deck Lift: Foot-controlled with Adapt system
• Discharge: Side standard; optional bagging/mulching
• Deck Engagement: Electric PTO

Engine

• Brand/Series: Kawasaki FX801V
• Displacement: 852 cc
• Power: V-Twin, gas-powered
• Speed: 3,750 RPM
• Air Filter: Heavy-duty canister
• Lubrication: Full pressure with oil filter
• Starter: Electric
