Description:

For more than 30 years, the Exmark Lazer Z has been the choice of more landscape professionals than any other zero-turn mower. For pros that demand the absolute best durability, productivity, cut quality and innovation, the Lazer Z X-Series is the number one choice. With more configuration options than any other Exmark mower, the Lazer Z X-Series is the pinnacle of state-of-the-art commercial mowers. Choose from 52-, 60-, or 72-inch UltraCut Series 6, or massive 96-inch UltraCut Rear Discharge cutting decks. Our exclusive flow control baffles and Adapt tools-free deck rake adjustment deliver Exmark Signature cut quality and higher cutting speeds in any mowing conditions. Powered by a choice of state-of-the-art big block EFI V-Twin commercial engines from Kawasaki, Kohler and Vanguard, the Lazer Z X-Series powers through the largest jobs with ease. A long-travel full suspension operator seat features isolation bumpers to deliver a smoother ride for reduced operator fatigue.

When you’re looking for the pinnacle of power, performance, cut quality and durability in a commercial zero-turn mower, the Lazer Z X-Series is the obvious choice. Be sure to check out our other Lazer Z models as well, including the Lazer Z Diese.

Specifications:

• UPC: 193308242149
• Width / Cutting Deck: 72"
• Drive: Hydro-Drive
• Starter: Electric

Steering & Tires

• Steering Control: Hydraulically dampened twin levers, adjustable fore/aft, with 2-position height adjustment and 3-position dampers
• Caster Forks: 0.50" thick caster yoke arms
• Front Caster Tires: 13 x 6.5-6, smooth tread, semi-pneumatic
• Drive Tires: 24 x 12-12, 4-ply Grassmaster TL

Safety & Braking

• Safety Package: Operator Presence Controls (OPC) and drive system interlock with safety interlock indicators
• Parking Brake: Lever-actuated disc brake

Frame & Construction

• Tractor Frame: Unibody, welded, heavy-duty 1.5" x 3" tubular steel
• Blade Spindles: No-maintenance, sealed, non-greasable spindles (7.75" cutter housing, 30mm spindle shaft, splined blade driver)
• Deck Style: Floating Deck (UltraCut Series 6, heavy-duty spindle, side discharge standard, optional bagging/mulching)
• Deck Construction: 10-gauge top, 7-gauge side skirt, 7-gauge spindle mounting

Engine & Transmission

• Engine Brand: Kohler
• Engine Model: ECV980
• Engine Series: Command Pro™ EFI
• Engine Displacement: 999 cc
• Engine Spec: ECV980
• Engine Speed: 3,650 RPM
• Air Filter: Heavy-duty canister air filtration system
• Fuel System: Electronic Throttle Body
• Fuel Type: Gas EFI
• Fuel Capacity: 12-gallon single fuel tank
• Transmission: Infinitely variable speed selection
• Speed: 0–11.5 mph (forward), 0–7.0 mph (reverse)
• Drive Description: Two Exmark exclusive Parker unitized pump & wheel motor systems with integrated cooling, shock valve, spin-on filter
• Drive Wheel Release: Allows movement without engine running

Cutting System

• Cutting Heights: 1.0" to 5.5" (0.25" increments)
• Blade Tip Speed: ~18,500 fpm
• Blades: 3 blades (24.50" each)

Controls & Features

• PTO Engagement: MagStop Electromagnetic 250-ft-lb clutch with spot brake
• Fuel Indicator: Electronic sender
• Deck Lift: Foot-controlled lift with Adapt system
• ROPS: 2-post foldable ROPS with seat belt and latch
• Carb Compliant: No

Dimensions & Weight

• Width: 84.9"
• Height: 70.5"
• Length: 86.1"
• Curb Weight: 1,304 lbs.

Comfort & Extras

• Seat: Deluxe, three-tone bolstered suspension seat with Elastomeric Vibration Control, isolation system for comfort
• Standard Features: Engine hour meter, USB plug-in, LED lights, phone tray, cup holder
