Description:

The Exmark Navigator zero-turn mowers, available in 42-inch and 48-inch deck widths, set the standard for lawn perfection. These professional-grade mowers feature patented fill-reduction technology that enhances airflow for superior vacuuming and debris collection, complemented by a larger diameter blower. Ideal for landscape professionals, both the 42-inch and 48-inch models offer exceptional controllability, responsiveness, and reduced hand force. A standout feature of the Navigator is its higher blade tip speed, which cuts grass into finer particles for a cleaner finish. The center-discharge deck, with its two-sided trimming capability, ensures precise control over discharge, keeping flower beds and walkways immaculate. Capable of speeds up to 7 mph, the Navigator makes achieving a nearly flawless lawn quick and efficient. For those looking to expand their fleet with top-tier equipment, our range of zero-turn mowers offers the perfect solution.

Specification:

• UPC: 193308000282
• Starter: Electric
• Steering Control: FeatherTouch hand-control drive levers, low-force constant speed lever
• Front Caster Tires: 8 x 3.0-4 semi-pneumatic
• Drive Tires: 18 x 10.5-10 Multi-Trac® C/S
• Parking Brake: Wet disc, internal in wheel motor
• Tractor Frame: Channeled and fully welded 1.5" x 1.5" x 0.187" wall tubing with 4.0" ground clearance, continuous force counterweight springs
• Blade Spindles: Heavy-duty cast iron right-angle gearboxes
• Electrical: 12-volt battery with 15-amp alternator
• Seat: Commercial grade, high back, contoured foam padded with hinged mounting
• Transmission Brand: Hydro-Gear
• Engine Brand: Kohler
• Transmission Speeds: Infinitely variable
• Engine Model: CH740
• Engine Displacement: 725 cc
• Engine Series: Command™
• Speed: Infinitely variable from 0–7.0 mph (11.3 km/h) forward, 0–4.5 mph (7.2 km/h) reverse
• Transmission: Hydrostatic
• Drive: Hydro-Drive
• Engine Spec: 3182
• Engine Speed: 3,600 rpm
• Air Filter: Heavy-duty canister air filtration
• Fuel Capacity: 7.5 gallons (28.4 L), pivoting tank for easier engine service
• Drive Description: Dual Hydro-Gear 12 cc variable displacement pumps powering Hydro-Gear H Series motors
• Fuel Type: Gas, carbureted
• PTO Engagement: Lever-actuated clutching belt with 6" brake band
• Drive Wheel Release: Allows movement without engine running
• Fuel Indicator: Translucent visual
• Deck Lift: Deck latch for easier height of cut adjustment
• Carb Compliant: No
• Safety Package: Operator Presence Controls (OPC) and drive system interlock
• ROPS: Optional 2-post foldable ROPS with seat belt and latch
• Deck Style: Floating Deck
• Deck Style Description: Full floating center discharge cutting deck with patented Fill Reduction Baffles and heavy-duty gear driven spindle assembly
• Width / Cutting Deck: 42"
• Deck Construction: 7-gauge sides with continuous bead weld, 10-gauge top, 3/16" wear guard, 7-gauge deck spindle supports, 0.25"-thick strap steel deck supports
• Cutting Heights: 1.0" (2.54 cm) to 4.0" (10.2 cm) in 0.25" (0.64 cm) increments
• Blade Tip Speed: Approximately 18,500 fpm
• Bag Capacity: 9.5 bushels (76 gallons)
• Blades: 2 blades at 22" length
• Width: 43.2 in. (109.7 cm)
• Height: 51.2 in. (130.0 cm)
• Length: 91.8 in. (233.2 cm)
• Curb Weight: 1173 lbs
