Description:

Features:

• 7-Iron™ PRO Side Discharge or Fastback™ Rear Discharge Deck
• Diesel Engine
• Compatible with select front blade, snow blower and broom attachments

Specifications:

Engine

• Manufacturer/Model: 3TNV88C
• Power: 37.4 hp (27.5 kW) gross @ 3000 rpm
• Cylinders: 3
• Displacement: 100.2 cu in (1.64 L)
• Torque: 80.4 lb-ft (109 Nm) @ 1950 rpm
• Fuel Type: Diesel (B20 compatible)
• Fuel Tank Capacity: 16 gal (60.6 L)
• Cooling: Liquid
• Cooling Capacity: 8 qt (7.6 L)
• Air Cleaner: Dual element dry type
• Air Restriction Indicator: Standard
• Charging System: Automotive type
• Alternator: 75 amp
• Battery: 12 V

Transmission / Drivetrain

• Type: Hydrostatic 2WD (optional full-time or on-demand 4WD)
• Speed Control: Two-pedal foot
• Cruise Control: Optional
• Hi/Lo Range: Single speed
• Forward Speed: 0–12 mph (0–19.3 km/h)
• Reverse Speed: 0–5 mph (0–8 km/h)

Hydraulics

• Type: Open center
• Pump Capacity: 5.1 gpm (19.3 L/min)
• Spool Valve: Front lift (standard)
• Lift Cylinders: 2

Steering

• Type: Hydraulic cylinder
• Turns Lock-to-Lock: 1.5–2 turns

Brakes

• Type: Internal wet disk
• Individual Turn Brakes: Standard
• Master Brake: Standard, locking

Tires

• Drive Wheels: 23x10.5-12 (optional 23x8.5-12)
• Steering (2WD): 18x8.5-8
• Steering (4WD): 18x8.5-10

Dimensions

• Wheelbase: 49.2 in (125 cm)
• Ground Clearance: 6.5 in (16.5 cm)
• Length (less mower): 86.7 in (220.2 cm)
• Width (Narrow 23x10.5 tires): 51.8 in (131.6 cm)
• Width (Wide 23x10.5 tires): 60.3 in (153.2 cm)
• Height with ROPS up: 82.7 in (210 cm)
• Height with ROPS folded: 58 in (147 cm)
• Shipping Weight (2WD): 1800 lb (816 kg)
• Shipping Weight (4WD): 1960 lb (889 kg)

ROPS

• Type: Standard folding
• Certifications: OSHA, CSA, SAE, EU, ISO

Mower Deck

• Construction: 7-Iron PRO, one-piece stamped steel
• Thickness: 7 gauge (0.180 in / 4.6 mm)
• Sizes Available: 60 in (152 cm) or 72 in (183 cm)
• Deck Offset: Yes
• Cutting Height: 1–6 in (2.54–15.24 cm)
• Blade Tip Speed: 18,000 fpm (5,486 m/min)
• Belt Tensioning: Spring-loaded
• Caster Wheels: Flat-free, 11x4-5
• Anti-Scalp Rollers: Front and rear gauge wheels

Warranty

• Coverage: 24 months
