Description:

Features:

• Standard LED headlights and fender lights
• Comfortable, marine-grade seat stays in top condition
• Larger, heavier frame for added stability
• Up to 72" AutoConnect™ mid-mower deck can be installed or removed in under 5 minutes

Specifications :

• Engine and Performance
• Manufacturer: Yanmar®
• Engine Model: 3TNV88C-NJT
• Engine Power (Gross): 27.4 kW (36.7 hp), SAE J1995 rated power at 2500 rpm
• PTO Power: 22.7 kW (30.4 hp)
• Rated Engine Speed: 2500 rpm
• Engine Type: Direct Injection, Turbocharged
• Emissions Compliance: Final Tier 4
• Cylinders/Displacement: 3 cylinders, 1.568 L (95.8 cu in.)
• Bore and Stroke: 86x90 mm (3.39x3.54 in.)
• Compression Ratio: 19.1:1
• Engine Torque at Rated Speed: 104.7 Nm (77.2 lb-ft)
• Lubrication: Pressurized system
• Cooling System: Water pump
• Fuel Tank Capacity: 32 L (8.5 U.S. gal.)
• Air Cleaner: Dual element
• Battery Size: 500 CCA
• Alternator (12-V): 85 amp
• Starter Size: 1.4 kW (1.9 hp)
• Transmission and Drive
• Transmission Type: Hydrostatic Transmission (HST)
• Forward/Reverse: Standard
• Cruise Control: Standard
• Differential Lock: Yes
• Final Drive: Spur gear
• Brakes: Wet disc
• Steering: Power steering
• Axle Capacity:
• Front Axle: 880 kg (1940 lb)
• Rear Axle: 1800 kg (3968 lb)
• Hydraulics
• Hydraulic System Type: Open center
• Pump Rated Output:
• Steering: 15 L/min (4 gpm)
• Implement: 20.2 L/min (5.3 gpm)
• Total: 35.2 L/min (9.3 gpm)
• Pump Type: Dual gear
• Maximum Operating Pressure: 172 bar (2495 psi)
• Remote Control Valves Available: Up to 3
• 3-Point Hitch
• Hitch Type: Category 1
• Lift Capacity (24 in. behind link arms): 615 kg (1356 lb)
• Draft Control Sensing: Position control
• Power Take-Off (PTO)
• PTO Speeds:
• Rear PTO: 543 rpm
• Mid PTO: 1998 rpm
• Clutch: Wet disc
• Brake for Mid and Rear PTO: Wet disc
• Dimensions
• Wheelbase: 1723 mm (67.8 in.)
• Turning Radius with Brakes: 2.46 m (8.07 ft.)
• Approximate Shipping Weight:
• Open Station: 1320 kg (2910 lb)
• Cab: Not applicable
• Tires
• Front Tires:
• R1 Ag: 7.00-12
• R3 Turf: 23x8.50-14
• R4 Industrial: 23x8.50-14
• R3 Turf Radial: 200/60 R15
• Rear Tires:
• R1 Ag: 12.4-16
• R3 Turf: 14-17.5
• R4 Industrial: 14-17.5
• R3 Turf Radial: 300/70 R20
• Operator Station
• Platform Type: Semi-flat
• Rollover Protective Structure (ROPS): Foldable
• ASABE S478 Standard
• Operator Station Features:
• Tilt Steering Wheel: Yes
• Toolbox: Yes
• 12-V Outlet: Yes
