Description:

Features:

• Standard four-wheel drive (4WD) for maximum traction
• Tightest turning radius in its horsepower class
• Hydro transmission with Twin Touch™ pedals for ease of use

Specifications:

• Engine Power (Gross):
• SAE J1995 Rated Power: 18.2 kW (24.4 hp)
• 24.7 PS at 2400 rpm
• Power Take-Off (PTO) Power:
• 13 kW (17.4 hp)
• Steering Hydraulics:
• 15 L/min (4 gpm)
• Implement Hydraulics:
• 20.2 L/min (5.3 gpm)
• Hitch Type:
• Category 1
• Lift Capacity (24-in. behind link arms):
• 615 kg (1356 lb)
• Transmission Type:
• Standard: Hydrostatic Transmission (HST)
• Cruise Control:
• Optional
• Approximate Shipping Weight:
• Open Operator Station (OOS): 1181 kg (2603 lb)
• Cab: Not applicable
• Wheelbase:
• 1593 mm (62.7 in)
• Key Engine Specifications
• Manufacturer: Yanmar
• Engine Model: 3TNV88F-EPJT2
• Engine Type: Diesel
• Fuel System: Direct injection
• Aspiration: Natural
• Emissions Compliance: Final Tier 4
• Number of Cylinders: 3
• Displacement: 1.64 L (100.2 cu in)
• Cylinder Liners: Cast-in-block
• Bore and Stroke: 88 x 90 mm (3.46 x 3.54 in)
• Compression Ratio: 19.1:1
• Lubrication: Pressurized
• Cooling System: Water pump
• Air Cleaner: Dual element
• Engine Torque at Rated Speed: 72.4 Nm (53.4 lb-ft)
• Rated Engine Speed: 2400 rpm
• Fuel Tank Capacity:
• 28.5 L (7.5 U.S. gal.)
• Electrical System
• Battery Size: 500 CCA
• Alternator (12-V): 55 amp
• Starter Size: 1.4 kW (1.9 hp)
• Transmission and Drive
• Transmission Type: Open center
• Final Drive Type: Spur gear
• Clutch Type: Wet disk
• Axle Capacity:
• Front: 880 kg (1940 lb)
• Rear: 1200 kg (2645 lb)
• Creeper: No
• Cruise Control: Optional
• Differential Lock: Yes
• Hydraulic System
• Pump Rated Output:
• Steering: 15 L/min (4 gpm)
• Implement: 20.2 L/min (5.3 gpm)
• Total: 35.2 L/min (9.3 gpm)
• Pump Type: Dual gear
• Maximum Operating Pressure: 172 bar (2495 psi)
• Draft Control Sensing: Position control
• Remote Control Valves Available: Up to two (optional)
• PTO (Power Take-Off)
• Standard PTO: Rear - 540 rpm
• Clutch: Wet disk
• Brake (for mid and rear PTO): Wet disk
• Control: Independent
• Fluid Capacities
• Crankcase with Filter: 4.5 L (4.8 U.S. gal)
• Transmission and Hydraulic System: 20.8 L (22 qt)
• Operator Station
• Type: Foldable Rollover Protective Structure (ROPS)
• Platform: Straddle
• Gear Shift Location: Left-hand side
• Wheelbase: 1593 mm (62.7 in)
• Front Axle Clearance:
• Minimum: 299 mm (11.8 in)
• Maximum: 333 mm (13.1 in)
• Turning Radius (without Brakes): 2.9 m (9.4 ft)
• Tire Specifications
• Front Tires:
• R1 Bar: 7-14
• R3 Turf: 27x8.5-15
• R4 Industrial: 25x8.5-14 or 27x8.5-15
• Rear Tires:
• R1 Bar: 11.2-24
• R3 Turf: 41x14-20
• R4 Industrial: 15-19.5 or 43x16-20
