Description:

Features:

• Standard four-wheel drive (4WD) for maximum traction
• Hydro transmission with Twin Touch™ pedals for ease of use
• Category 1 3-pt hitch compatible with dozens of implements

Specifications:

• Engine and Performance
• Engine Model: Yanmar 3TNV86CT-NJT2
• Engine Power (Gross): 27.4 kW (36.7 hp) at 2500 rpm
• Power Take-Off (PTO) Power: 22.4 kW (30 hp)
• Rated Engine Speed: 2500 rpm
• Engine Type: Diesel, Turbocharged
• Injection Pump Type: High pressure common rail direct injection
• Emissions Compliance: Final Tier 4
• Cylinders/Displacement: 3 / 1.57 L (95.7 cu in.)
• Engine Torque at Rated Speed: 104.7 Nm (77.2 lb-ft)
• Fuel Tank Capacity: 28.5 L (7.5 gal.)
• Battery Size: 500 CCA
• Alternator (12-V): 55 amp
• Starter Size: 1.4 kW (1.9 hp)
• Lubrication: Pressurized
• Cooling System: Water Pump
• Air Cleaner: Dual element
• Transmission and Drivetrain
• Transmission Type: Hydrostatic transmission (HST)
• Cruise Control: Optional
• Final Drive: Spur gear
• Differential Lock: Yes
• Brakes: Wet disk
• Steering: Power steering
• Pump Rated Output:
• Steering: 15.0 L/min (4.0 gpm)
• Implement: 20.2 L/min (5.3 gpm)
• Total Pump Output: 35.2 L/min (9.3 gpm)
• Maximum Operating Pressure: 172 bar (2495 psi)
• Transmission Fluid Capacity: 20.8 L (22 qt)
• Hydraulics and Hitch
• Hydraulics Type: Open center
• Lift Capacity (24-in. Behind Link Arms): 615 kg (1356 lb)
• 3-Point Hitch Type: Category 1
• Draft Control Sensing: Position control
• Remote Control Valves Available: Up to two (optional)
• Rear PTO: 540 rpm (Independent)
• Dimensions and Weight
• Wheelbase: 1593 mm (62.7 in.)
• Front Axle Clearance:
• Minimum: 299 mm (11.8 in.)
• Maximum: 333 mm (13.1 in.)
• Turning Radius Without Brakes: 2.9 m (9.4 ft)
• Approximate Shipping Weight:
• Open Operator Station (OOS): 1210 kg (2668 lb)
• Cab: Not applicable
• Tires and Wheels
• Front Tires:
• R1 Bar: 7-14
• R3 Turf: 27x8.5-15
• R4 Industrial: 25x8.5-14, 27x8.5-15
• Rear Tires:
• R1 Bar: 11.2-24
• R3 Turf: 41x14-20
• R4 Industrial: 15-19.5, 43x16-20
• Operator Station and Other Features
• Operator Station Type: Foldable ROPS, Platform - flat/straddle
• Gear Shift Location: Left-hand side
• Hitch Type: Category 1 (Standard)
• Fluid Capacities
• Crankcase with Filter: 4.5 L (4.8 gal.)
• Transmission and Hydraulic System: 20.8 L (22 qt)
