Description:

Features:

• Auto Connect™ deck compatible for deck attach/detach in seconds
• Cab or Open Station configuration available
• Powr Reverser™ or E-hydro transmission with Twin Touch™ pedals

Specifications:

• Engine Model: 3TNV86CT-MJT
• Engine Power (Gross): SAE J1995 rated power: 28.5 kW (38.2 hp, 38.7 PS at 2600 rpm)
• Engine Type: Diesel, Turbocharged
• Injection Pump Type: High-pressure common rail direct injection
• Aspiration: Turbocharged
• Emissions Compliance: Final Tier 4
• Cylinders/Displacement: 3 cylinders / 1.57 L (95.7 cu in)
• Number of Cylinders: 3
• Bore & Stroke: 86 x 90 mm (3.4 x 3.54 in.)
• Compression Ratio: 19.1:1
• Engine Torque at Rated Speed: 105 Nm (77.4 lb-ft)
• Lubrication: Pressurized
• Cooling System: Liquid
• Air Cleaner: Dual element
• Power Take-Off (PTO) Specifications
• PTO Power:
• PowrReverser Transmission: 24.4 kW (32.8 hp)
• eHydro Transmission: 22.2 kW (29.8 hp)
• PTO Type: Independent rear 540 rpm (eHydro: Mid - 2100 rpm optional)
• PTO Clutch: Wet disk
• Hydraulics & Steering
• Steering Hydraulics: 23.5 L/min (6.2 gpm)
• Implement Hydraulics: 34.3 L/min (9.1 gpm)
• Pump Rated Output:
• Steering: 23.5 L/min (6.2 gpm)
• Implement: 34.3 L/min (9.1 gpm)
• Total: 57.8 L/min (15.3 gpm)
• Maximum Operating Pressure: 172 bar (2495 psi)
• Hydraulic Pump Type: Single gear
• Hydraulic Type: Open center
• Remote Control Valves Available: Up to six rear remotes
• Transmission & Drive
• Transmission Type:
• PowrReverser Transmission: 12F/12R
• eHydro Transmission: Three-range, infinitely variable
• Final Drive: Spur gear
• Cruise Control:
• PowrReverser Transmission: Not applicable
• eHydro Transmission: Standard
• Brakes: Wet disk
• Steering: Hydrostatic power steering
• Clutch (for PowrReverser): Wet disk
• Dimensions & Capacity
• Wheelbase: 1727 mm (68 in.)
• Front Axle Clearance: 171 mm (6.7 in.) - 299 mm (11.8 in.)
• Turning Radius (with Brakes): 2.7 m (8.8 ft)
• Turning Radius (without Brakes): 2.8 m (9.2 ft)
• Weight (Approximate Shipping):
• Open Operator Station (OOS) PowrReverser Transmission: 1363 kg (3005 lb)
• OOS eHydro Transmission: 1382 kg (3047 lb)
• Cab eHydro Transmission: 1676 kg (3695 lb)
• Lift Capacity & Hitch
• Lift Capacity (24-in. Behind Link Arms): 995 kg (2194 lb)
• Hitch Type: Category 1
• 3-Point Hitch Compatibility: Category 1
• PTO Gear: Independent rear, 540 rpm
• Fluid Capacities
• Engine Crankcase with Filter: 4.3 L (4.5 gal.)
• Transmission & Hydraulic System:
• PowrReverser Transmission: 24.6 L (6.5 U.S. gal.)
• eHydro Transmission: 26.5 L (7 U.S. gal.)
• Tires & Dimensions
• Front Tires (Options):
• R1 Bar: 7-14
• R3 Turf: 27x8.50-15
• R3 Turf Special: 25/10.5LLx15
• R4 Industrial: 25x8.5-14 or 27x8.5-15
• Rear Tires (Options):
• R1 Bar: 11.2-24
• R3 Turf: 41x14-20
• R3 Turf Special: 41x18LL-16.1
• R4 Industrial: 15-19.5 or 43x16-20
• Front Tread Range: 1117 mm (44 in.)
• Rear Tread Spacing: 1031 mm (40.6 in.)
