Description:

Features:

• AutoConnect™ deck compatible for deck attach/detach in seconds
• Cab or Open Station configuration available
• Standard hydrostatic transmission with Twin Touch™ pedals

Specifications:

• Engine Manufacturer: Yanmar®
• Engine Model: 3TNV86CHT-MJTV
• Engine Power (gross):
• 33.3 kW (44.7 hp, 45.3 PS at 2600 rpm)
• Rated Engine Speed: 2600 rpm
• Engine Torque at Rated Speed: 112.3 Nm (90 lb-ft)
• Fuel Type: Diesel
• Fuel System: High pressure common rail direct injection
• Aspiration: Turbocharged and intercooled
• Emissions Compliance: Final Tier 4
• Cylinders/Displacement: Three cylinders, 1.57 L (95.7 cu in.)
• Cylinder Liners: Cast-in-block
• Compression Ratio: 19.1:1
• Lubrication: Pressurized
• Cooling System: Liquid
• Air Cleaner: Dual element
• Fuel Tank Capacity:
• Open Operator Station (OOS): 37.4 L (10 U.S. gal.)
• Cab: 47.6 L (12.6 U.S. gal.)
• Battery: 500 CCA
• Alternator (12-V): 75 amp
• Starter Size: 1.4 kW (1.9 hp)
• Transmission & Hydraulics
• Transmission Type: eHydro (three-range, infinitely variable)
• Final Drive: Spur gear
• Hydrostatic Power Steering: Standard
• Brakes: Wet disk
• Hydraulics:
• Steering: 23.5 L/min (6.2 gpm)
• Implement: 34.3 L/min (9.1 gpm)
• Total Pump Output: 57.8 L/min (15.3 gpm)
• Maximum Operating Pressure: 172 bar (2495 psi)
• Pump Type: Single gear
• Remote Control Valves: Up to six rear remotes
• Lift Capacity (24 in. behind link arms): 995 kg (2194 lb)
• PTO (Power Take-Off)
• Rear PTO Speed: 540 rpm (standard)
• Mid PTO Speed: 2100 rpm (optional)
• PTO Power: 25.2 kW (33.9 hp)
• PTO Clutch: Wet disk
• Brake (for mid and rear PTO): Wet disk
• Dimensions & Weight
• Wheelbase: 1727 mm (68 in.)
• Approximate Shipping Weight:
• Open Operator Station (OOS): 1391 kg (3066 lb)
• Cab: 1818 kg (4008 lb)
• Front Axle Clearance:
• Minimum: 171 mm (6.7 in.)
• Maximum: 299 mm (11.8 in.)
• Turning Radius:
• With brakes: 2.7 m (8.8 ft)
• Without brakes: 2.8 m (9.2 ft)
• Front Tread Range: 1117 mm (44 in.)
• Rear Tread Spacing: 1031 mm (40.6 in.)
• Tires
• Front Tire Options:
• R1 Bar: 7-14
• R3 Turf: 27x8.50-15
• R3 Turf Special: 25/10.5LLx15
• R4 Industrial: 25x8.5-14 or 27x8.5-15
• Rear Tire Options:
• R1 Bar: 11.2-24
• R3 Turf: 41x14-20
• R3 Turf Special: 41x18LL-16.1
• R4 Industrial: 15-19.5 or 43x16-20
• Operator Station
• Rollover Protective Structure (ROPS):
• Type: Foldable
• Complies with OSHA, SAE, and CSA standards for rollover protection
• Visibility: 360-degree visibility
• Doors: Two
• Noise Rating: 80 dBA
• Seat Equipment: Scissor-link
• Additional Features
• Cruise Control: Standard
• Lift System: Category 1 3-point hitch
• Lift Capacity (24 in. behind link arms): 995 kg (2194 lb)
• Fluid Capacities:
• Crankcase with filter: 5.7 L (6 U.S. gal.)
• Transmission and hydraulic system: 26.5 L (7 U.S. gal.)
