Description:

• Naturally aspirated diesel engine
• PowrReverser™ or eHydrostatic Transmission Options
• Cab or Open Station configurations
• Premium features: Hitch Assist, Aux Hitch Control, HST controls

Specifications:

• Engine Power (Gross): 31.7 kW (42.5 hp, 43.1 PS) at 2600 rpm
• Power Take-Off (PTO) Power:
• PowrReverser™ Transmission: 25 kW (33.6 hp)
• eHydro™ Transmission: 24.1 kW (32.3 hp)
• Engine Type: Diesel, naturally aspirated
• Engine Model: 4TNV88C-MJT
• Engine Displacement: 2.189 L (133.5 cu in.)
• Cylinders: 4
• Bore and Stroke: 88 mm x 90 mm (3.46 in. x 3.54 in.)
• Compression Ratio: 19.1:1
• Fuel System: High-pressure common rail direct injection
• Torque at Rated Speed: 116 Nm (85.6 lb-ft)
• Lubrication: Pressurized
• Cooling System: Liquid-cooled
• Air Cleaner: Dual element with electronic restriction indicator
• Emissions Compliance: Final Tier 4
• Fuel Tank Capacity:
• ROPS: 56.9 L (15 U.S. gal.)
• Cab: 52.2 L (13.8 U.S. gal.)
• Battery Size: 770 CCA
• Alternator (12-V): 75 amp
• Starter Size: 2 kW (2.68 hp)
• Transmission & Hydraulics
• Transmission Type:
• Standard: eHydro™ (eHST) - Infinitely-variable, 3-range
• Optional: 12/12 PowrReverser™ transmission (PRT)
• Transmission Gear Ranges:
• PRT: 12F/12R
• eHydro: Infinitely-variable
• Final Drive: Planetary
• Brakes: Multi-plate wet disc
• Steering: Hydrostatic power steering
• Clutch: Wet, 129 mm (5.08 in.)
• Hydraulics:
• Steering Pump Output: 23.5 L/min (6.2 gpm)
• Implement Pump Output: 42.3 L/min (11.2 gpm)
• Total Pump Output: 65.8 L/min (17.4 gpm)
• Remote Control Valves: Up to six rear remotes
• Draft Control Sensing: Position control
• Hydraulic System Type: Open center
• 3-Point Hitch & PTO
• Hitch Type: Category 1
• Lift Capacity (24-in. behind link arms): 1135 kg (2500 lb)
• PTO:
• Standard: Independent 540 rpm at 2600 rpm
• Optional: 540E rpm
• Clutch: Wet disc
• Dimensions
• Wheelbase: 185.5 cm (73 in.)
• Front Axle Clearance: 35.1 cm (13.8 in.)
• Turning Radius with Brakes: 2.8 m (9.17 ft)
• Turning Radius without Brakes: 3.0 m (9.84 ft)
• Approximate Shipping Weight:
• Open-station: 1710 kg (3770 lb)
• Cab: 2120 kg (4675 lb)
• Front Tread Range: 148.1 cm (58.3 in.)
• Rear Tread Spacing: 137.2 cm (54 in.)
• Tires
• Front Tires:
• Farm: 8-16
• Turf: 27x10.5-15 or 27x12LL-15
• Industrial: 10-16.5
• Rear Tires:
• Farm: 13.6-28
• Turf: 44x18-20 or 22.5LL-16.1
• Industrial: 16.9Lx24
• Operator Station
• Operator Station: Foldable ROPS, flat platform
• Visibility: 360-degree visibility
• Air Conditioning: Yes, with a 14.4 °C (58 °F) temperature differential
• Doors: Two
• Noise Rating: 78 dBA
• Seat: Air suspension with swivel
• Miscellaneous Features
• Differential Lock: Yes
• Cruise Control: Standard
• Creeper: SpeedMatch standard
• Fluid Capacities:
• Crankcase with Filter: 5.3 L (1.4 gal.)
• Transmission and Hydraulic System: 47.3 L (12.5 gal.)
