Description:

• Turbocharged diesel engine
• PowrReverser™ or eHydrostatic Transmission Options
• Cab or Open Station configurations
• Premium features: Hitch Assist, Aux Hitch Control, HST controls

Specifications:

• Engine Power (Gross):
• SAE J1995 Rated Power: 48.5 kW (65 hp)
• 65.9 PS at 2600 rpm
• Power Take-Off (PTO) Power:
• PowrReverser™ Transmission: 40.4 kW (54.2 hp)
• eHydro™ Transmission: 38.7 kW (51.9 hp)
• Steering Hydraulics:
• 23.5 L/min (6.2 gpm)
• Implement Hydraulics:
• 42.3 L/min (11.2 gpm)
• Hitch Type:
• Category 1
• Lift Capacity (24-in. behind link arms):
• 1135 kg (2500 lb)
• Transmission Type:
• Standard: eHydro Transmission (eHST)
• Optional: 12/12 PowrReverser™ Transmission (PRT)
• Cruise Control:
• Standard
• Approximate Shipping Weight:
• Open Operator Station (OOS): 1710 kg (3770 lb)
• Cab: 2120 kg (4675 lb)
• Wheelbase:
• 185.5 cm (73 in)
• Key Engine Specifications
• Manufacturer: Yanmar
• Engine Model: 4TNV86CHT-MJT
• Engine Type: Diesel
• Fuel System: High pressure common rail direct injection
• Aspiration: Turbocharged and charge air cooled
• Emissions Compliance: Final Tier 4
• Number of Cylinders: 4
• Displacement: 2.091 L (127.6 cu in)
• Cylinder Liners: Cast-in-block
• Bore and Stroke: 86 x 90 mm (3.4 x 3.54 in)
• Compression Ratio: 19.1:1
• Lubrication: Pressurized
• Cooling System: Liquid
• Air Cleaner: Dual element with electronic restriction indicator
• Engine Torque at Rated Speed: 178 Nm (131.3 lb-ft)
• Rated Engine Speed: 2600 rpm
• Fuel Tank Capacity:
• Open Operator Station (ROPS): 56.9 L (15 U.S. gal.)
• Cab: 52.2 L (13.8 U.S. gal.)
• Electrical System
• Battery Size: 770 CCA
• Alternator (12-V): 75 amp
• Starter Size: 2 kW (2.68 hp)
• Transmission and Drive
• Transmission Gear Ranges:
• PRT: 12F/12R
• eHydro: Infinitely-variable 3-range
• Clutch Type: Wet disc
• Clutch Disk Diameter (Wet Clutch): 129 mm (5.08 in)
• Axle Capacity:
• Front: 1600 kg (3528 lb)
• Rear: 2400 kg (5292 lb)
• Creeper: SpeedMatch standard
• Differential Lock: Yes
• Final Drive Type: Planetary
• Brakes: Multi-plate wet disc
• Steering Type: Hydrostatic power steering
• Hydraulic System
• Pump Rated Output:
• Steering: 23.5 L/min (6.2 gpm)
• Implement: 42.3 L/min (11.2 gpm)
• Total: 65.8 L/min (17.4 gpm)
• Pump Type: Single gear
• Draft Control Sensing: Position control
• Remote Control Valves Available: Up to six rear remotes
• PTO (Power Take-Off)
• Standard PTO: Independent 540 rpm at 2600 rpm
• Optional PTO: 540E rpm
• Clutch: Wet disc
• Control: Independent
• Fluid Capacities
• Crankcase with Filter: 5.3 L (1.4 gal)
• Transmission and Hydraulic System: 47.3 L (12.5 gal)
• Operator Station
• Type: Foldable Rollover Protective Structure (ROPS)
• Platform: Flat
• Gear Shift Location (PRT): Left-hand side
• Visibility: 360-degree
• Air Conditioning: 14.4°C (58°F) temperature differential
• Noise Rating: 78 dBA
• Seat Equipment: Air suspension with swivel
• Doors: Two
• Compliance: OSHA, SAE, ASAE
• Dimensions
• Front Tread Range: 148.1 cm (58.3 in)
• Rear Tread Spacing: 137.2 cm (54 in)
• Front Axle Clearance: 35.1 cm (13.8 in)
• Turning Radius (with Brakes): 2.8 m (9.19 ft)
• Turning Radius (without Brakes): 3.0 m (9.84 ft)
• Tire Specifications
• Front Tires:
• Farm: 8-16
• Turf: 27x10.5-15 or 27x12LL-15
• Industrial: 10-16.5
• Rear Tires:
• Farm: 13.6-28
• Turf: 44x18-20 or 22.5LL-16.1
• Industrial: 16.9Lx24
