Description:

Features:

• Power Reverser™, Power Quad™ PLUS or Powr8™ transmission options
• Choose climate-controlled cab or open station
• Hitch lift capacity starting at 5,150 lb (2,336 kg) and optional up to 7,860 lb (3,565 kg)

Specifications:

• Engine
• Model: John Deere Power Tech™ 4045 EWL
• Type: Turbocharged, air-to-air aftercooled
• Displacement: 4.5 L (276 cu in.), 4-cylinder
• Rated Power: 95 hp (70.0 kW) @ 2200 rpm
• Max Power: 97.8 hp (73.0 kW)
• Rated PTO Power: 80 hp (58.8 kW) @ 2100 rpm
• Peak Torque: 396 Nm (292 lb-ft) @ 1600 rpm
• PTO Torque Rise: 30%
• Emissions: Final Tier 4, DOC/SCR aftertreatment
• Transmission
• Standard: PowrReverser™ 16F/16R
• Optional: PowrReverser™ Hi-Lo 32F/16R, PowrQuad™ PLUS 16F/16R, Powr8™ 32F/16R (w/ or w/o creeper)
• Clutch: Wet
• Reverser: Electrohydraulic (left hand)
• Hydraulics
• Type: Open center
• Pump Output:
• PowrReverser™: 94 L/min (24.7 gpm)
• PowrQuad™/Powr8™: 97 L/min (25.6 gpm)
• SCVs:
• Rear: 2 standard, 3 optional
• Mid: 2 standard, up to 3 optional
• Joystick SCV Control: Mechanical
• Hitch
• Category: Category 2, convertible to 1
• Lift Capacity:
• PowrReverser™ Standard: 5150 lb (2336 kg)
• PowrReverser™ Optional: 5950 lb (2699 kg)
• PowrQuad™/Powr8™ Standard: 6970 lb (3161 kg)
• PowrQuad™/Powr8™ Optional: 7860 lb (3565 kg)
• Sensing Type: Lower link
• Draft Control: Mechanical or electrohydraulic
• PTO
• Type: Independent, electrohydraulic
• Speeds:
• 540 @ 2100 rpm
• 540E @ 1645 rpm
• 1000 @ 2100 rpm
• Rear PTO Shaft: 540/540E (6-spline), optional 1000 rpm (21-spline reversible)
• Front PTO: 1000 rpm (21-spline)
• Drawbar
• Category: 2
• Vertical Load Capacity:
• Max Road/Field (250 mm): 1450 kg (3197 lb)
• Extended Field (350–400 mm): 1200 kg (2646 lb)
• Axles & Drive
• Rear Axle: Inboard planetary w/ electrohydraulic diff lock
• Front Axle:
• Standard: MFWD
• Optional: 2WD
• Final Drive: Flange standard, optional rack-and-pinion (bar)
• Tires & Turning
• Rear Tires: 18.4R30 (460/85R30) R1W Radial
• Tread Range:
• Front MFWD: 51.1–78.6 in.
• Rear: 53.1–90 in.
• Turning Radius:
• With brakes: 2WD – 12.04 ft, MFWD – 12.6 ft
• Without brakes: 2WD – 12.6 ft, MFWD – 13.1 ft
• Electrical
• Alternator:
• OOS: 90 amp
• Cab: 120 amp
• ISOBUS: 200 amp
• Lights: Standard halogen, optional LED
• Battery: 12V
• Operator Station
• ROPS: Foldable, rigid
• Platform: Flat
• Seat:
• Standard: Mechanical
• Optional: Air ride / Premium air ride
• Noise Level: 78 dBA
• Display:
• PowrReverser™: LED cluster
• PowrQuad™/Powr8™: Digital dash w/ LCDs
• Optional: Radio, instructional seat
• Dimensions & Weight
• Wheelbase: 92.5 in. (2350 mm)
• Overall Length: ~160–161 in. (OOS/Cab)
• Shipping Weight (approx.):
• 2WD OOS: 8140 lb
• 2WD Cab: 8580 lb
• MFWD OOS: 8765 lb
• MFWD Cab: 9185 lb
• Base Weight:
• PowrReverser™: 8298 lb (3764 kg)
• PowrQuad™/Powr8™: 8740 lb (3964 kg)
• Capacities
• Fuel Tank:
• Open Station: 37.7 gal (142.7 L)
• Cab: 43.7 gal (165.4 L)
• DEF Tank: 3.17 gal (12.0 L)
