Description:

Features:

• John Deere PowerTech™ Diesel Engine with FT4 emissions compliance
• Standard 12F/12R PowrReverser™ Transmission and MFWD only
• Premium cab, standard cab, or open operator station available
• 1000 RPM PTO dealer-installed option available

Specifications:

Engine:

• Engine Description: John Deere PowerTech™ 4045 PWL
• Engine Type: 4045HLV76
• Engine Family: NJDXL04.5315
• Displacement: 4 cylinders, 4.5 L (276 cu in)
• Aspiration: Turbocharged and Aftercooled
• Cylinders Liners: Wet sleeved
• Emission Level: Final Tier 4
• After Treatment Type: DOC/SCR
• Rated Speed: 2400 rpm
• Rated Power (at 2400 rpm): 74.6 kW (100 hp)
• Maximum Engine Power: 76.0 kW (102 hp)
• Rated PTO Power (at 2400 rpm): 63.4 kW (85 hp)
• Engine Peak Torque (at 1700 rpm): 384 Nm (283 lb-ft)
• Power Boost (at 2200 rpm): 2%

Transmission:

• Type: PowrReverser™ 12F/12R (Standard), PowrReverser™ Hi-Lo 24F/12R (Optional)
• Reverser: Yes
• Clutch Type: Wet
• Transmission Type: Open center

Hydraulic System:

• Pump Rated Output: 85.1 L/min (22.5 gpm)
• Available Flow (at Single Rear SCV): 60.1 L/min (15.9 gpm)
• Number of Rear SCVs (Standard/Optional): 2 / 3
• Number of Mid SCVs (Standard/Optional): 0 / Up to 3
• Joystick SCV Control: Mechanical
• Remote Control Valves Available: 2 (Standard), 3 (Optional)
• Hitch Draft Control Load Sense Type: Mechanical
• Rear Hitch Category: Category 2 (Convertible to 1)
• Maximum Lift Capacity (Standard): 2100 kg (4600 lb)
• Hitch Sensing Type: Top Link

Rear Hitch:

• Drawbar Category: Category 2
• Maximum Vertical Load:
• Road/Field Use (250-mm Extended): 1450 kg (3197 lb)
• Field Use (350-mm Extended): 1200 kg (2646 lb)
• Field Use (400-mm Extended): 1200 kg

PTO (Power Take-Off):

• Type: Flange
• PTO Actuation: Electrohydraulic
• PTO Speeds:
• 540 at 2400 rpm
• 540E at 1716 rpm
• 1000 at 2400 rpm
• Rear PTO Type: 540/540E (Standard), 540/1000 (Optional)

Brakes and Axles:

• Brake Type: Hydraulic wet disc
• Rear Axle Type: Mechanical Front Wheel Drive (MFWD)
• Front Axle Type: MFWD: 18.4-30 R1 Bias
• Turning Radius with Brakes (MFWD): 4.36 m (14.3 ft)
• Turning Radius without Brakes (MFWD): 3.54 m (11.6 ft)
• Differential Controls: Mechanical (pedal)

Tires:

• Front Tire Tread Range (MFWD): 1340–1904 mm (52.8–75.0 in.)

Electrical System:

• Alternator Size: OOS: 90 amp, Cab: 120 amp
• Battery Options: 12 V
• Working Lights: Halogen
• Headlight Bulb Type: Halogen
• Beacon Bulb Type: Halogen (Kit)

Operator Station:

• Rollover Protective Structure (ROPS): Rigid, foldable, telescopic (Two-post)
• Seat Type: Mechanical (Standard), Air Ride (Optional for Cab)
• Instructional Seat: Optional for Standard Cab, Included with Premium Cab
• Display: Automotive-style LED instrument cluster
• Inner Cab Volume: 78 dBA
• Gearshift Location: Floor

Dimensions:

• Wheelbase: 2350 mm (92.5 in.)
• Overall Length: 4042 mm (159.13 in.)
• Approximate Shipping Weight:
• Open: 3300 kg (7275 lb)
• Cab: 3700 kg (8150 lb)

Weight and Fuel:

• Fuel Tank (OOS): 94.6 L (25 U.S. gal.)
• Fuel Tank (Cab): 114 L (30 U.S. gal.)
• Diesel Exhaust Fluid (DEF) Tank: 12.0 L (3.17 U.S. gal.)
