Description:

• 23.5-hp (17.5-kW)
• 48" deck, 7-gauge fabricated deck
• Mow up to 8 mph
• Warranty: 36 months or 1200 hours, whichever comes first. First 24 months, no hour limitation

Specifications:

• Manufacturer/Model: FX730V
• Power: 23.5 hp (17.5 kW) at 3,600 rpm
• Displacement: 44.3 cu in (726 cc)
• Cylinders: Two, V-twin
• Crankcase Capacity (with filter): 2.2 qt (2.1 L)
• Oil Filter: Full flow, replaceable
• Lubrication: Full pressure
• Cooling System: Forced air with integrated clean-out ports
• Air Cleaner: Heavy-duty canister type with safety element
• Fuel Type: Gasoline
• Fuel Tank Capacity: 5.6 U.S. gal (21.2 L)
• Fuel Tank Shut-off Valve: Yes
• Charge System: 20A at 3,600 rpm
• Battery Voltage: 12 V
• Cold Cranking Amp (CCA): 300
• Hour Meter: Digital
• Operator Presence Starting System: Yes
• Transmission & Drivetrain:
• Transmission: Separate hydraulic pumps and motors
• Hydraulic Pumps: 0.61 cu in (10 cc)
• Wheel Motors: 12 cu in (196 cc)
• Travel Speed:
• Forward: Infinite, 0-8 mph (0-12.9 km/h)
• Reverse: Infinite, 0-3.5 mph (0-5.6 km/h)
• Speed and Direction Control: Twin hand-controlled levers
• Hydraulic Capacity (with filter, dry): 5 qt (4.7 L)
• Hydraulic Oil Cooler: Radiator core
• Brake Type: Electro-magnetic with 125 lb-ft (169 Nm) of torque
• Brakes: Dual hand-controlled levers for dynamic braking, park brake engaged by hand lever
• Mower Deck:
• Deck Size: 48-in. (122 cm), fabricated steel with floating mount system
• Deck Construction: 7-gauge, 0.180 in. (4.6 mm) thickness
• Blades: Three high-lift blades, 0.25 in. (0.64 cm) thickness
• Blade Tip Speed: 18,000 fpm (5,486 m/min)
• Height-of-Cut Range: 1.5-5 in. (3.8-12.7 cm), adjustable in 0.25 in. (0.64 cm) increments
• Discharge: Side
• Front Anti-scalp Rollers: Double-captured center
• Caster Wheels: 11x4-5, flat-free
• Dimensions & Weight:
• Length: 59.75 in. (151.8 cm)
• Width (with chute down): 62 in. (157 cm)
• Height: 46 in. (117 cm)
• Weight: 800 lb (363 kg)
• Tires:
• Drive Wheels: 18x10.5-10 pneumatic
• Caster Wheels: 11x4-5, flat-free
• Tire Load Rating: 4 PR
• Warranty:
• Duration: 36 months or 1200 hours, whichever comes first
• First 24 months: No hour limitation
