Description:

Features:

• Electric motor with on-board charging
• Quiet, zero-emissions operation
• External LED battery charge indicator
• Large versatile cargo box

Specifications:

• Electrical System
• Voltage: 48 V
• Battery: Eight Trojan® T-105 batteries
• Capacity: 12 kWh
• Charger: High-frequency switched-mode, 120V AC, 60Hz, 12A input, 48VDC output (IEC320/C14 connector)
• Drive and Motor System
• Motor: Wound direct drive, 48 VDC separately excited motor
• Controller: Separately excited, 400 amp maximum
• Features include: Anti-rollaway braking and alarm, anti-stall motor protection, regenerative braking, diagnostic indicator, full torque, reduced speed reverse.
• Transaxle: 16.99:1 ratio with helical gearing
• Drive System: Dual rear wheel mechanical drum
• Gear Selection: Forward, neutral, reverse
• Brakes and Suspension
• Brake Type: Dual rear-wheel mechanical drum
• Park Brake: Hand-operated, multi-latch
• Front Suspension: Independent, spring over shock, single A-arm with 127mm (5 in.) total travel
• Rear Suspension: Not specified, with two high-flotation, low-pressure tires.
• Steering: Rack and pinion
• Dimensions and Capacities
• Vehicle Weight: 630 kg (1389 lb)
• Length:
• Without bumper: 2664 mm (104.9 in.)
• With bumper: 2728 mm (107.4 in.)
• Width: 1524 mm (60 in.)
• Height: 1130 mm (44.5 in.)
• Ground Clearance:
• Under transaxle: 196 mm (7.7 in.)
• Under foot platform: 185 mm (7.3 in.)
• Wheelbase: 194 cm (76.4 in.)
• Turning Clearance Circle: 6.7 m (22 ft)
• Cargo Capacity
• Payload Capacity: 408 kg (900 lb)
• Towing Capacity: 272 kg (600 lb)
• Cargo Box Volume: 460 L (16.4 cu ft)
• Cargo Box Material: Polypropylene side panels and tailgate; steel floor and load guard
• Tailgate: Hinged at the bottom, removable; side panels are also removable
• Dump System: Manual, with optional power lift
• Height Above Ground: 762 mm (30 in.)
• Seating and Interior
• Seating Capacity: Two
• Seat Type: Professional high back bucket, tilt forward, with optional seat adjustment
• Seating Dimensions:
• Length: 1143 mm (45 in.)
• Inside Width: 1321 mm (52 in.)
• Depth: 304.8 mm (12 in.)
• Capacity: 272 kg (600 lb)
• Tires
• Front Tires: Two 22x9.5-10, 4-ply high-flotation turf
• Rear Tires: Two 24x12-10, 4-ply high-flotation turf
• Additional Features
• Battery Discharge Indicator: Yes
• Reverse Warning Indicator: Yes
• Operator Presence Switch: Yes
• Hour Meter: Yes
• Headlight Switch: Yes
• Storage: Two cup holders, glove box
• Frame: Mig welded uni-body, high-strength steel
• Ground Pressure: 0.6 bar (8.6 psi) with a fully loaded 200 lb operator
• Other Key Specs
• Chassis: Durable construction with TPO - Rubber and Polypropylene
• Charger Input: 120V AC, 12A input, 15A breaker maximum
• Charger Output: 48VDC nominal, 21 ADC output
• AC Power Cord: 2.4 m (94 in.)
