Description:

• 48-inch (122-cm) floating mower deck
• Powerful 19 hp (14.2 kW) V-twin engine
• Self-propelled hydrostatic drive system
• Easy-to-use controls for operator comfort and convenience

Specifications:

• Manufacturer/Model: FX600V
• Engine Power (at 3600 rpm):
• 19 hp (14.2 kW)
• Displacement: 36.8 cu in. (603 cc)
• Cylinders: V-twin
• Operating Speed: 3,600 rpm
• Ignition/Starter: Electronic/electric start
• Valving: Overhead valves
• Oil Filter: Standard
• Lubrication: Full pressure
• Governor: Flyweight all-speed governor
• Cooling System: Air-cooled
• Air Cleaner: Heavy-duty air cleaner
• Muffler: Low tone
• Fuel Type: Gasoline
• Fuel Tank Capacity: 5.4 U.S. gal. (20.4 L)
• Fuel Pump: Vacuum-operated diaphragm
• Fuel Delivery System: Carburetor
• Fuel Pickup: Top draw
• Fuel Tank Switch/Shut-off Valve: No
• Ignition: Electronic spark
• Hourmeter: Standard, digital
• Operator Presence Starting System: PTO off, park brake engaged, speed lever in neutral

Transmission & Drivetrain:

• Transmission:
• Two Hydro-Gear™ 0.73-cu in. (10-cc) hydraulic pumps
• Danfoss 12 cu-in. (197-cc) wheel motors
• Ergonomic handles with spring-loaded neutral lock
• Shift Mechanism: Ergonomic handles with spring-loaded neutral lock
• Wheel Motors: Danfoss 12 cu in. (197 cc)
• Drive Wheels: 18x8.5-8
• Caster Wheels: 9x3.5-4 semi-pneumatic
• Drivetrain: Hydro-Gear™ hydraulic drive system with variable forward and reverse speeds

Speed & Performance:

• Speed Range:
• Forward: 0-7.5 mph (0-12.1 km/h)
• Reverse: 0-3 mph (0-4.8 km/h)
• Travel Speed:
• Infinite forward and reverse speeds
• Dynamic braking with hand controls
• Hand lever to set parking brake

Mower Deck Specifications:

• Deck Size: 48 in. (122 cm)
• Deck Construction:
• 10-gauge, 0.14-in. (3.42-mm) fabricated steel deck top
• 10-gauge, 0.14-in. (3.42-mm) spindle mounting plate
• 7-gauge, 0.19-in. (4.8-mm) side skirts with reinforcement bar
• Blades:
• Three high-lift blades
• Length: 16.5 in. (41.9 cm)
• Thickness: 0.25 in. (0.64 cm)
• Blade Drive: V-Belt
• Blade Tip Speed: Approximately 18,000 fpm (5,486 m/min)
• Cutting Height: 1.5-4.5 in. (3.8-11.4 cm)

Dimensions:

• Height: 44.8 in. (114 cm)
• Length (with deck): 74 in. (188 cm)
• Width:
• Deflector down: 62 in. (157 cm)
• Deflector up (for storage): 50 in. (127 cm)
• Weight: 705 lb (320 kg)

Warranty:

• 36 months or 1200 hours, whichever comes first
• First 24 months: No hour limitation
