Description:

Features:

• HVAC cab with easy-to-clean vinyl seats
• Powerful diesel engine with up to 4,000-lb (1814 kg) towing capacity
• Power steering
• Class-leading cargo box volume*

Specifications:

• Engine
• Type: 4-cycle diesel
• Power: 17.0 kW / 22.8 hp
• Displacement: 854 cc
• Cooling System: Liquid
• Fuel Capacity: 42.4 L / 11.2 U.S. gal
• Transmission & Drivetrain
• Transmission: Continuously Variable Transmission (CVT) with clutch enclosure
• Final Drive: Park, High, Low, Neutral, Reverse (transaxle)
• Drive System: Dash switch-actuated 4WD
• Traction Assist:
• Limited-slip front differential
• Switch-actuated locking rear differential
• Descent Control: Yes
• Suspension
• Front: Independent dual A-arm with adjustable coils (203 mm / 8 in. travel)
• Rear: Independent dual A-arm with adjustable coils and sway bar (229 mm / 9 in. travel)
• Brakes
• Type: Hydraulic disc brakes (twin piston front calipers)
• Parking Brake: In-transmission; optional secondary foot-operated with hand release
• Tires & Wheels
• Front Tires:
• 27x9-R14 Maxxis® Bighorn® 2.0
• or 27x9-R14 Predator Heavy-Duty
• Rear Tires:
• 27x11-R14 Maxxis® Bighorn® 2.0
• or 27x11-R14 Predator Heavy-Duty
• Wheels: Steel or alloy
• Dimensions
• Length: 3250 mm / 128 in
• Width (mirrors folded): 1790 mm / 70.5 in
• Height: 2030 mm / 79.9 in
• Wheelbase: 2211 mm / 87 in
• Ground Clearance: 305 mm / 12 in
• Tread Centers:
• Front: 1376 mm / 54.2 in
• Rear: 1300 mm / 51.2 in
• Capacities
• Weight (with fluids): 1073 kg / 2366 lb
• Payload Capacity: 469 kg / 1034 lb
• Towing Capacity: Up to 1814 kg / 4000 lb
• Hitch: 5.1 cm / 2 in (standard receiver)
• Cargo Box Dimensions: 1099 x 343 x 1392 mm / 43.3 x 13.5 x 54.8 in
• Cargo Volume: 524 L / 18.5 cu ft
• Cargo Box Capacity (Weight): 454 kg / 1000 lb
• Features
• Power Steering: Yes
• Colors Available:
• Green and yellow
• TrueTimber® KANATI® camo
• Olive and black
• Electrical
• Battery: 12V, 480 CCA
• Alternator: 85 amp
• Power Ports:
• 12V DC outlet
• 12V cargo box power port
• Instrumentation
• Digital display showing:
• Gear position
• Diagnostic lights
• Speed, RPM
• 4WD & differential indicators
• Fuel level, coolant temp
• Hour meter, mileage, service interval
• Storage
• Total Storage: 69.5 L / 18.4 gal
• Under Seat: 55.3 L / 14.6 gal
• Other Storage:
• 6 cup holders: 4.6 L / 1.2 gal
• Center tray: 1.2 L / 0.3 gal
• Dash bins (2): 3.3 L / 0.9 gal
• Glove box: 3.8 L / 1.0 gal
• Storage pocket: 1.4 L / 0.4 gal
• Seating
• Type: Black vinyl 40/60 split
• Capacity: 3 passengers (bench seat)
