Description:

Features:

• Mow up to 2 acres
• 20 HP* (14.9 kW) V-Twin engine
• 42-in. (107 cm) Accel Deep™ Mower Deck
• Maximum forward speed 7 mph (11.2 km/h) with 3-gal. (13.6-litre) fuel tank
• 3-year/200-hour bumper-to-bumper warranty.

Specifications:

Engine

• Power: 20 hp (14.9 kW)
• Engine Model Number: 40 EXi
• Displacement: 40 cu in. (656 cc)
• Cylinders: V-twin
• Lubrication: Full pressure with replaceable filter (capacity: 2 U.S. qt / 1.9 L)
• Engine Type: Overhead valve
• Choke/Speed Control: Single lever
• Cooling Method: Air
• Fuel Tank Capacity: 3.0 U.S. gal. (11.4 L)
• Fuel Gauge: Translucent tank
• Battery: 12 V, 300 CCA

Drive System

• Drive Train: Dual hydros, Hydro-Gear EZT-C with 1-in. (2.5 cm) axles
• Forward Speed: 0-7 mph (0-11.3 km/h)
• Reverse Speed: 0-3.5 mph (0-5.6 km/h)
• Speed and Direction Control: Twin levers
• Control Adjustment: 3 height, 11 positions
• Maximum Towing Capacity: 250 lb (113 kg)

Tires

• Front Caster Tires: 11x6-5
• Drive Tires: 18x8.5-8
• Front Caster Bearings: Sealed ball bearings

Dimensions

• Wheelbase: 49.4 in. (1255 mm)
• Overall Length: 75.4 in. (1915 mm)
• Width (without mower): 43.3 in. (1100 mm)
• Width (with mower): 50.4 in. (1280 mm)
• Width (with mower, deflector raised for storage): 46.5 in. (1180 mm)
• Height: 41.6 in. (1056 mm)
• Weight: 554 lb (252 kg)

Mower Deck

• Width of Cut: Accel Deep™ mower deck, 42 in. (107 cm)
• Deck Type: Side discharge
• Mower Deck Material: 12 gauge (0.105 in. / 2.7 mm)
• Mower Drive System: V-belt
• Mower Deck Type: Electric, 105 lb-ft (142 Nm)
• Cutting Height: 1.25-4.5 in. (3-11 cm)
• Cut Height Increments: 0.25 in. (0.64 cm)
• Preset Cut Height: Yes

Seat & Operator Features

• Seat Back Height: High back with optional armrests, 18 in. (46 cm)
• Seat Suspension: Two springs
• Fore-Aft Adjustment: 2.9 in. (7 cm)
• Seat Type: Foot lift
• Operator Presence System: Yes
• Park Brake Interlock: Yes
• Rollover Protective Structure (ROPS): No
• Slope Operating Limit: 13 degrees; 10 degrees with Material Collection System (MCS)

Safety & Operation

• Operator Video: Yes, available online
• Integrated Park Brake: Automatically applied when steering levers are stowed outward
• Durable Mower Deck: 12-gauge steel with double-captured mower wheels
• Height Adjustment: Easily change from 1.25 to 4.5 in. (3 to 11 cm) using foot lift and cutting height dial

Warranty

• Warranty: 3 years or 200 hours bumper-to-bumper (limited by years or hours used, whichever comes first)
