Description:

Features:

• Mow up to 2 acres
• 21.5 HP* (16 kW) V-Twin engine
• 42-in. (107 cm) Accel Deep™ Mower Deck
• 20-inch (50.8 cm) high-back custom-tailored seat with arm rests
• 3-year/200-hour bumper-to-bumper warranty

Specifications:

Engine

• Engine Power: 21.5 hp (16.0 kW)
• Engine Model Number: FR651V
• Displacement: 44.3 cu in. (726 cc)
• Cylinders: V-twin
• Lubrication: Full pressure with replaceable filter, 2.2 U.S. qt (2.1 L) capacity
• Type: Overhead valve
• Battery: 12 V, 300 CCA
• Choke/Speed Control: Separate levers
• Cooling Method: Air
• Fuel Tank Capacity: 3.0 U.S. gal. (11.4 L)
• Fuel Gauge: Translucent tank

Transmission and Drive

• Drive Train: Dual hydros, Hydro-Gear EZT-C with 1-in. (2.5-cm) axles
• Forward Speed: 0-7 mph (0-11.3 km/h)
• Reverse Speed: 0-3.5 mph (0-5.6 km/h)
• Speed and Direction Control: Twin levers
• Control Adjustment: 3 height, 11 positions

Mower Deck Specifications

• Cutting Width: 42 in. (107 cm)
• Mower Deck Material: 12 gauge (0.105 in., 2.7 mm)
• Mower Drive System: V-belt
• Mower Type: Side discharge
• Mower PTO: Electric, 105 lb-ft (142 Nm)
• Mower Wheel Adjustment: Captured double mower wheels
• Mower Lift System: Foot lift
• Mower Cut Height: 1.25-4.5 in. (3-11 cm)
• Cut Height Increments: 0.25 in. (0.64 cm)
• Preset Cut Height: Yes
• Mower Wash Port: No

Dimensions and Weight

• Overall Width (with mower): 50.4 in. (1280 mm)
• Width with Mower (Deflector Raised for Storage): 46.5 in. (1180 mm)
• Width without Mower: 43.3 in. (1100 mm)
• Overall Length: 75.4 in. (1915 mm)
• Height: 43.3 in. (1100 mm)
• Wheelbase: 49.4 in. (1255 mm)
• Weight: 572 lb (260 kg)

Steering and Comfort

• Seat Type: High back with armrests
• Seat Back Height: 20 in. (51 cm)
• Fore-Aft Adjustment: 2.9 in. (7 cm)
• Seat Suspension: Two springs
• Control: Twin levers, 3 height, 11 positions for comfort

Safety and Operation

• Operator Presence System: Yes
• Park Brake Interlock: Yes
• Integrated Park Brake: Automatically applied when steering levers are stowed outward
• Slope Operating Limit: 13 degrees; 10 degrees with Material Collection System (MCS)
• Operator Video: Yes, online

Additional Features

• Mulching System: Optional MulchControl™ attachment
• Rubber Floor Mat: Standard
• Sun Shade: Optional
• Light Kit: Standard
• Material Collection System: Two-bag cut-and-throw MCS, 6.5 bu (229 L)

Warranty

• Warranty: 3 year/200 hour bumper-to-bumper (term limited to years or hours used, whichever comes first)
