Description:

Features:

• 24 hp* (17.9 kW) V-Twin engine
• 48-in (122 cm), 54-in (137cm) and 60-in (152 cm) Accel Deep™ deck, compatible with optional MulchControl™ kit
• 18-in. cut and sewn seat with armrests and easy to read fuel gauge
• 4-year/300-hour bumper-to-bumper warranty

Specifications:

Engine

• Engine Power: 24 hp (17.9 kW)
• Engine Model: M44 Extended Life Series (ELS)
• Engine Type: Overhead valve, full pressure with replaceable filter
• Displacement: 44.2 cu in. (724 cc)
• Cylinders: V-twin
• Lubrication: Full pressure with replaceable filter (Capacity: 2 U.S. qt / 1.9 L)
• Choke/Speed Control: Separate levers
• Cooling Method: Air
• Fuel Tank Capacity: 4.5 U.S. gal. (17 L)
• Fuel Gauge: Electric gauge and fuel level sight line
• Battery: 12 V, 300 CCA
• Fuel Delivery: Carburetor (pulse pump)
• Hour Meter: Yes
• Storage Compartment: Yes
• Cup Holder: Yes

Drive Train

• Transmission Type: Dual hydros, Tuff Torq® TZT7-U with 1-in. (2.5-cm) axles
• Speed and Direction Control: Twin levers
• Forward Speed: 0-8 mph (0-12.9 km/h)
• Reverse Speed: 0-4 mph (0-6.4 km/h)
• Control Adjustment: 2-height/9-fore-aft, 18 positions
• Drive Tires: 22x9.5-10
• Front Caster Tires: 13x6.5-6
• Front Caster Bearings: Sealed ball bearings
• Maximum Towing Capacity: 250 lb (113 kg)

Chassis and Frame

• Frame: Heavy-duty frame tubing
• Primer/Paint: E-coat/powder
• Rollover Protective Structure (ROPS): Yes
• Slope Operating Limit: 15 degrees (10 degrees with an MCS)
• Operator Presence System: Yes
• Park Brake Interlock: Yes
• Storage Compartment: Yes

Seat

• Seat Type: Medium back with armrests
• Seat Back Height: 18 in. (45.7 cm)
• Fore-Aft Adjustment: 3 in. (7.6 cm) while seated
• Seat Suspension: Two springs
• Cup Holder: Yes

Mower Deck

• Deck Type: Accel Deep™ mower deck
• Width of Cut:
• 54 in. (137 cm)
• 60 in. (152 cm)
• Mower Deck Material: 10 gauge (0.135 in. / 3.4 mm)
• Mower Drive System: V-belt
• PTO: Electric, 105 lb-ft (142.4 Nm)
• Mower Deck: Side discharge
• Mulching System: Optional MulchControl™ attachment
• 54 in. (137 cm)
• 60 in. (152 cm)
• Mower Wash Port: Yes
• Mower Cut Height: 1-4 in. (2.5-10.2 cm)
• Cut Height Increments: 0.25 in. (0.64 cm)
• Preset Cut Height: Yes

Dimensions

• Wheelbase: 49.2 in. (1250 mm)
• Overall Length: 76.9 in. (1953 mm)
• Width Without Mower: 46.6 in. (1184 mm)
• Width with Mower:
• 48A: 62.8 in. (1595 mm)
• 54A: 68.6 in. (1742 mm)
• 60A: 73.4 in. (1864 mm)
• Width with Mower (Deflector Raised for Storage):
• 48A: 53.9 in. (1370 mm)
• 54A: 59.7 in. (1517 mm)
• 60A: 65.6 in. (1667 mm)
• Height:
• ROPS in folded position: 48.6 in. (1235 mm)
• ROPS in raised position: 71.1 in. (1806 mm)
• Weight (With Mower and Fuel):
• 54A: 776 lb (353 kg)
• 60A: 784 lb (356 kg)

Mower Operation and Safety

• Operator Video: Yes
• Note 1: Mower wash port makes cleaning the deck easier
• Note 2: Flip-up foot platform for easy service access
• Note 3: 18-position adjustable motion-control levers

Warranty

• Warranty: 4 years or 300 hours bumper-to-bumper* (*Term limited to years or hours used, whichever comes first)

Optional Equipment

• Mulching System: Optional MulchControl attachment (54 in. / 137 cm and 60 in. / 152 cm)
• Rubber Floor Mat: Optional
• Sun Shade: Optional
• Light Kit: Optional 4-point LED Light kit
• Material Collection System (MCS): Power Flow rear bagger, 6.5 bu (230 L) (Not available on 60A)
• Protective Cover: No
• Mounted Sprayer: No
