Description:

Features:

• 7-Iron™ PRO deck
• Mulch On Demand™ Available
• Gasoline Engine
• Propane Option Available
• Rear Discharge Deck

Specifications:

Engine

• Manufacturer/Model: Kawasaki FX801V
• Power: 25.5 hp (19 kW) @ 3,600 rpm (gross)
• Displacement: 852 cc (52 cu in.)
• Cylinders: 2
• Cooling: Air-cooled
• Lubrication: Full pressure
• Oil Capacity: 2.4 U.S. qt (2.3 L) with filter
• Oil Filter: Full-flow, replaceable
• Air Cleaner: Heavy-duty canister type with pre-cleaner and safety element
• Fuel Type: Gasoline
• Fuel Consumption: 1.1–1.9 U.S. gal/hr (4.2–7.2 L/hr), depending on load
• Fuel Tank Capacity: 11.5 U.S. gal. (43.5 L)
• Fuel Shut-off Valve: Yes

Electrical System

• Charging System: 30 amp
• Battery Voltage: 12 V
• Cold Cranking Amps: 300 amp
• Hour Meter: Digital, standard
• Operator Presence System: Brake-N-Go (hand operated)

Transmission & Drivetrain

• Type: Hydrostatic
• Wheel Motors: Tuff Torq heavy-duty integrated piston motors
• Hydraulic Capacity: 5.9 U.S. qt (5.6 L)
• Hydraulic Filter: Internal, replaceable
• Speed (Forward): 0–12 mph (0–19.3 km/h)
• Speed (Reverse): 0–4.5 mph (0–7.2 km/h)
• Speed Control: Twin levers
• Dynamic Braking: Twin lever
• Park Brake: Internal wet disk, hand-actuated

Mower Deck – 60-in.

• Deck Types Available:
• 60-in. 7Iron™ PRO Side Discharge
• 60-in. 7Iron™ PRO Mulch On Demand™
• 60-in. FastBack™ PRO Rear Discharge
• Construction:
• 7-Iron PRO: One-piece, 7-gauge (0.179 in. / 4.6 mm) forged steel
• FastBack PRO: Fabricated 7-gauge steel
• Blade Count: 3
• Blade Tip Speed:
• 7Iron PRO: ~18,500 fpm
• FastBack PRO: ~16,500 fpm
• Cut Height Range: 1–5.5 in. (2.54–14 cm)
• Height Increments: 0.25 in. (0.64 cm)
• PTO Clutch: Electro-magnetic, 225 lb-ft (305 Nm)
• Drive Type: V-belt

Wheels & Tires

• Drive Wheels: 24x12-12 (4 PR rated)
• Caster Wheels: 13x6.5-6, flat-free
• Front Anti-Scalp Rollers: Right-hand, center, left-hand
• Rear Anti-Scalp Rollers: Standard

Dimensions & Weight

• Length: 84 in. (213 cm)
• Width (chute down): 74 in. (188 cm)
• Width (rear discharge): 63.5 in. (161.3 cm)
• Height (ROPS up): 73 in. (185 cm)
• Height (ROPS down): 47 in. (119 cm)
• Weight: 1,296 to 1,383 lb (588–627 kg)

Safety & Warranty

• ROPS: Yes
• Slope Operation Limit:
• 20° standard
• 10° with material collection system installed
• Warranty:
• 36 months / 1,200 hours
• First 24 months: No hour limit
