Description:

Features:

• 7-Iron™ PRO Mowing Deck
• Mulch On Demand™ Available
• Rear Discharge Deck
• Propane Option Available
• Cross-porting hydraulic transmission

Specifications:

Engine

• Manufacturer/Model: FX850V
• Power (Gross at 3,600 rpm): 27 hp (20.1 kW)
• Displacement: 52 cu in. (852 cc)
• Cylinders: Two
• Crankcase Capacity (with filter): 2.4 U.S. qt (2.3 L)
• Oil Filter: Full flow, replaceable
• Lubrication: Full pressure
• Cooling: Air
• Air Cleaner: Heavy-duty canister with safety element, pre-cleaner

Fuel System

• Fuel Type: Gasoline
• Fuel Tank Capacity: 11.5 U.S. gal (43.5 L)
• Fuel Consumption: 1.1-1.9 U.S. gal/hr (4.2-7.2 L/hr)
• Fuel Tank Switch/Shut-off Valve: Yes

Electrical System

• Charge System: 30 amp
• Battery Voltage: 12 V
• Cold Cranking Amp: 300 amp
• Hour Meter: Standard, digital
• Operator Presence Starting System: Brake-N-Go (foot)

Drivetrain

• Transmission: Hydrostatic
• Wheel Motors: Tuff Torq heavy-duty integrated piston wheel motor
• Travel Speed (Forward): 0-12 mph (19.3 km/h)
• Travel Speed (Reverse): 0-4.5 mph (7.2 km/h)
• Speed & Direction Control: Twin levers
• Hydraulic Capacity: 5.9 U.S. qt (5.6 L)
• Filter: Internal, replaceable

PTO

• Type: Electro-magnetic
• Torque: 225 lb-ft (305 Nm)
• Drive: V-belt

Mower Deck (60-in 7Iron PRO side-discharge)

• Deck Size: 60 in. (152 cm)
• Deck Construction: 7-gauge (0.179 in / 4.6 mm) one-piece forged steel
• Height of Cut Range: 1-5.5 in. (2.54-14 cm) in 0.25 in (0.64 cm) increments
• Blade Tip Speed: ~18,500 fpm
• Number of Blades: 3

Wheels & Tires

• Drive Wheels: 24x12-12
• Load Rating: 4 PR
• Caster Wheels: 13x6.5-6 (Flat free)
• Front Anti-Scalp Rollers: RH, center, LH
• Rear Anti-Scalp Rollers: Standard

Brakes

• Dynamic Braking: Twin levers
• Park Brake: Internal wet disk integrated in transmission
• Park Brake Actuation: Foot brake

Dimensions

• Length: 84 in. (213 cm)
• Width (chute down): 74 in. (188 cm)
• Height (ROPS up): 73 in. (185 cm)
• Height (ROPS down): 47 in. (119 cm)
• Weight: 1,315 to 1,423 lb (596 to 645 kg)

Operation & Safety

• ROPS: Yes
• Slope Operating Limit: 20 degrees (10 degrees with material collection system)

Warranty

• Warranty: 36 months or 1500 hours (First 24 months: no hour limitation)
