Description:

Features:

• 7-Iron™ PRO Mowing Deck
• Brake-N-Go starting
• Cross-porting hydraulic transmission
• Rear Discharge Deck

Specifications:

• Engine Manufacturer/Model: FX1000V
• Engine Power (Gross at 3,600 rpm): 35 hp (26.1 kW)
• Fuel Tank Capacity: 11.5 U.S. gal. (43.5 L)
• Mower Deck Size: 72-in. (183-cm) 7Iron™ PRO side-discharge / 72-in. (183-cm) FastBack™ PRO rear-discharge
• Blade Tip Speed: 7Iron PRO: Approximately 18,500 fpm / 72-in. (183-cm) FastBack: Approximately 18,000 fpm
• Transmission: Hydrostatic
• Speed Range: 0–12 mph (0–19.3 km/h) forward, 0–4.5 mph (0–7.2 km/h) reverse
• Drive Wheels: 24x12-12
• Caster Wheels: 13x6.5-6
• Deck Construction: 7-Iron™ PRO: 7-gauge, 0.179-in. (4.6-mm) one-piece forged steel / FastBack™ PRO: 7-gauge, 0.179-in. (4.6-mm) fabricated steel
• Height-of-Cut Range: 1–5.5 in. (2.54–14 cm), adjustable in 0.25 in. (0.64 cm) increments
• Cutting Width: 72 in. (183 cm)
• Blades: 3 Blades, 24.50 in. (62.23 cm) length
• Blade Tip Speed: 7Iron PRO: Approximately 18,500 fpm / 72-in. (183-cm) FastBack: Approximately 18,000 fpm
• Caster Wheel Type: Flat free
• Front Anti-Scalp Rollers: RH, center, LH
• Rear Anti-Scalp Rollers: Standard
• Weight: 1,326 to 1,445 lb (601 to 655 kg)
• Dimensions (Width): 74–86 in. (188–218 cm) with chute down, Rear discharge 75.8 in. (192.5 cm)
• Height: With ROPS up, 73 in. (185 cm); With ROPS down, 47 in. (119 cm)
• Slope Operating Limit: 20 degrees (10 degrees with material collection system installed)
• Warranty: 36 months or 1,500 hours, whichever comes first (first 24 months with no hour limitation)
