Description:

Features:

• 23-hp (17.2-kW)* iTorque™ Power System
• 48-in. (122 cm) Accel Deep™ mower deck, compatible with optional MulchControl™ kit with one-touch technology
• 18-in. cut and sewn seat
• 4 year/300 hour bumper-to-bumper warranty

Specifications:

• Engine and Power
• Engine Power: 23 hp (17.2 kW)
• Engine Manufacturer/Model: Kawasaki FR691V
• Engine Type: Overhead valve, full-pressure lubrication, oil filter
• Displacement: 44.3 cu in. (726 cc)
• Fuel Type: Gasoline
• Fuel System: Pulse pump, carburetor
• Fuel Tank Capacity: 3.3 U.S. gal. (12.5 L)
• Cooling Method: Air-cooled
• Oil Change: No-tools oil drain with replaceable filter
• Transmission
• Transaxle Type: K58 hydrostatic integrated with transaxle
• Control: Twin Touch™ pedals (for forward/reverse control)
• Forward Speed: 0-5.9 mph (0-9.5 km/h)
• Reverse Speed: 0-3.5 mph (0-5.6 km/h)
• Brakes: Internal wet disc
• Oil Cooler: Fins and fan on transaxle
• Chassis and Steering
• Frame: Welded heavy-duty
• Front Axle: Cast iron with front wheel ball bearings
• Steering Type: Manual, sector and pinion
• Turning Radius: 15 in. (38.1 cm)
• Wheelbase: 49.4 in. (1255 mm)
• Four-Wheel Steering: Yes
• Steering Wheel: 14 in. (35.6 cm) large, non-tilting
• Mower Deck
• Cutting Width: 48 in. (122 cm) Accel Deep™ mower deck
• Deck Material: 10 gauge (0.135 in. or 3.4 mm) forged steel shell
• Mower Deck Type: Side discharge
• Cut Height: 13 positions, 1-4 in. (2.5-10.2 cm), adjustable in 0.25 in. (0.64 cm) increments
• Mower Drive System: Electric PTO clutch, in-line belt
• Mower Wheels: Four, adjustable with seven-position spring-loaded pin
• Mower Wash Port: Yes
• Mower Level Adjustment: Exact Adjust ports and onboard deck-leveling gauge
• Dimensions
• Height: 49 in. (1244 mm)
• Overall Length: 71.5 in. (1817 mm)
• Width with Mower: 62.6 in. (1590 mm)
• Width with Mower (Deflector Raised for Storage): 52.6 in. (1335 mm)
• Width without Mower: 40.9 in. (1040 mm)
• Weight: 700 lb (318 kg) (mower, no fuel)
• Comfort and Features
• Seat Type: Cut-and-sewn high-back with 15-position fore-aft adjustment (6.6 in./17 cm travel)
• Seat Suspension: Tilt with two coil springs for operator weight adjustment (3-position, no-tools adjustment)
• Cup Holder: Yes
• Storage: Under seat and covered toolbox
• Foot Pedal Lift System: Adjustable spring assist
• Electrical System
• Battery: 12 V, 340 CCA
• Charging System: Flywheel alternator, regulated, 12 amp
• Headlights: Two standard, incandescent, 27 W
• Electrical Outlet: Optional 12-V outlet
• Hour Meter: Yes
• Towing Capacity
• Maximum Towing Capacity: 600 lb (272 kg)
• Hitch Type: Optional weight bracket for front and rear
• Receiver Hitch: No
• Safety Features
• Backup Protection: Reverse Implement Option (RIO)
• Meets ANSI and OPEI Standards: Yes
• Safety Video: Yes
• Warranty: 4-year/300-hour bumper-to-bumper warranty (terms limited by years or hours used)
• Optional Attachments and Equipment
• Mowers: 48A (standard)
• Mulching System: MulchControl™
• Rear Bagger: 7, 19 bu (247, 670 L)
• Snow Blower: Two-stage, 44 in. (111.8 cm)
• Front Blade: 44 in. (111.8 cm)
• Weather Protection: Weather enclosure, sun canopy
• Grass Striping: Lawn striping kit
• Tow-Behind Tools: Various sizes for spreaders, sprayers, etc.
• Additional Features
• Frame Paint: Durable E-coat primer and powder-paint finish
• Hood Material: Fully enclosed, molded-in color to reduce sound, rust, and dents
• Warranty Details
• Warranty: 4 years/300 hours, whichever comes first. Terms vary by model.
