Description:

Features:

• 23-hp (17.2-kW)* iTorque™ Power System
• 48-in. Accel Deep™ mower deck, compatible with optional Mulch Control™ kit with one-touch technology
• Power two-wheel steer
• 4 year/300 hour bumper-to-bumper warranty

Specifications:

Engine

• Engine Power: 23 hp (17.2 kW)
• Engine Manufacturer/Model: FR691V
• Displacement: 44.3 cu in. (726 cc)
• Cylinders: V-twin, cast-iron liners
• Lubrication: Full pressure with replaceable filter
• Fuel System: Pulse pump, carburetor
• Fuel Tank Capacity: 3.3 U.S. gal. (12.5 L)
• Fuel Gauge: Gauge on dash
• Choke/Speed Control: Separate levers, automatic choke return
• Cooling Method: Air
• Oil Change: No-tools oil drain with replaceable filter
• Battery: 12 V, 340 CCA

Transmission and Drive

• Transaxle Type: K58 hydrostatic integrated with transaxle
• Control: Twin Touch™ pedals
• Forward Speed: 0-6.2 mph (0-10 km/h)
• Reverse Speed: 0-3.5 mph (0-5.6 km/h)
• Transaxle: Internal wet disc brakes
• Drive System: Dual belt

Mower Deck Specifications

• Cutting Width: 48 in. (122 cm)
• Construction: Forged steel deck shell
• Mower Deck Material: 10 gauge (0.135 in., 3.4 mm)
• Mower Drive System: Electric power take-off (PTO) clutch, in-line belt
• Mower Wheels: Four
• Mower Wheel Adjustment: Seven-position, spring-loaded pin
• Mower Level Adjustment: Exact Adjust ports and onboard deck-leveling gauge
• Mower Wash Port: Yes
• Mower Attachability: Roll under tractor, quick-pull pins

Dimensions and Weight

• Overall Width (with mower): 62.6 in. (1590 mm)
• Width with Mower (Deflector Raised): 52.6 in. (1335 mm)
• Width without Mower: 39.4 in. (1000 mm)
• Overall Length: 72.3 in. (1836 mm)
• Wheelbase: 49.4 in. (1255 mm)
• Height: 49 in. (1244 mm)
• Weight (Mower, No Fuel): 678 lb (308 kg)

Steering and Comfort

• Steering: Power steering with tilt steering wheel
• Steering Wheel: Large, 14 in. (35.6 cm)
• Turning Radius: 22 in. (55.9 cm)
• Seat Type: Hydraulic, medium back with armrests
• Seat Back Height: 18 in. (46 cm)
• Fore-Aft Adjustment: While seated, 15-position, 6.6 in. (17 cm)
• Seat Suspension: Tilt, two coil springs, three-position no-tools adjustment

Safety and Operation

• Operator Presence System: Yes
• Park Brake Interlock: Yes
• Reverse Implement Option (RIO): Yes
• Safety Video: Yes
• Meets ANSI Standard: Yes
• Meets OPEI Standard: Yes

Additional Features

• Cruise Control: Yes, button on dash
• Cup Holder: Yes
• Storage: Under seat and covered toolbox
• Maximum Towing Capacity: 600 lb (272 kg)
• Hydraulic Lift System: Yes, side discharge
• Mower Cutting Height: 13 positions, 1-4 in. (2.5-10.2 cm)

Warranty

• Warranty: 4 year/300 hour bumper-to-bumper (term limited to years or hours used, whichever comes first)
